Dx51d Z100 Galvanized Steel Coil
Wanzhi Steel is a professional galvanized steel manufacturer in China, which is able to produce various specifications of galvanized steel, including Dx51d+Z100 galvanized steel coil.
Width: 600 – 1500mm
Thickness: 0.2 mm – 3.0 mm
Yield Strength: ≥ 280 MPa
Surface Treatment: Oiling, pre-painting, passivation, etc.
Ensure product quality and transportation
Dx51d Z100 Galvanized Steel Coil Specifications
Product Name | Dx51d Z100 Galvanized Steel Coil |
Width | 600 – 1500mm |
Thickness | 0.3 mm – 3.0 mm |
Length | Cutting according to demand |
Material | Dx51d |
Zinc Coating | Z100g/m² (total weight of both sides 100g/m²) |
Yield Strength | ≥ 280 MPa |
Tensile Strength | 270 – 500 MPa |
Elongation | ≥ 22% |
Surface Treatment | Oiling, pre-painting, passivation, etc. |
Spangle Type | Zero Spangle, Small Spangle, Regular Spangle, Big Spangle |
Packaging | Standard airworthy packaging or as required |
Meaning of DX51D+Z100
Meaning of DX51D
- DX51D is a steel grade defined according to the European standard EN 10346.
- D means that the steel is suitable for cold forming processes (e.g. stamping, bending, etc.).
- X means that the steel base material is mild steel.
- 51 indicates that the steel has a minimum yield strength of 280 MPa.
Meaning of Z100
- Z100 indicates the weight of the galvanized coating.
- Z stands for Zinc Coating.
- 100 indicates a total weight of 100 g/m² of galvanized coating on both sides, normally 50 g/m² on one side.
- The range of Wanzhi Steel’s zinc coatings is 30 – 275 g/m². Commonly used zinc coating weights in the market include Z60, Z80, Z100, Z120, Z150, Z180, Z200 and so on.
Recommended zinc coating weights for different environments
- Lightly corrosive environments (e.g. dry indoor environments): Z60, Z80.
- Moderately corrosive environment (e.g. outdoor normal climate): Z100, Z120.
- Heavy corrosive environment (such as coastal, industrial area): Z150, Z180, Z200.


Main Features of DX51D+Z100 Gi coils
- Corrosion resistance: The zinc layer provides excellent protection against erosion and extends the service life of the steel.
- Formability: DX51D steel has good ductility and formability, suitable for stamping, bending and other processing.
- Surface quality: The galvanized layer is uniform and smooth, and different surface treatments can be provided according to needs (such as smooth surface, small zinc flowers, no zinc flowers, etc.).
- Mechanical properties: It has high hardness and tensile strength, as well as good fatigue resistance and impact resistance.


DX51D+Z100 Galvanized Steel Coil Applications
- Construction field: can be used to manufacture roof and wall materials (such as galvanized corrugated sheet, Color galvanized sheet, metal carved board, etc.). It is also used to manufacture steel structural parts, purlins, supports, etc.
- Home appliance field: It is a common material for manufacturing refrigerators, washing machines, air conditioners and other home appliance shells and internal structural parts.
- Automotive field: used for the manufacture of car bodies, doors, chassis parts and other parts.
- Other fields: It is also widely used in furniture frames, ventilation ducts, cable trays, agricultural equipment, storage shelves and other scenes.
Why Choose Us
- With two galvanized steel production lines, we are able to produce galvanized steel coils of various specifications.
- Our company is ISO 9001:2015 certified and our products are successfully exported to more than 120 countries.
- With a complete testing center, our products undergo strict testing, including performance, specification and zinc layer testing.
- With equipment for longitudinal shearing, cut-to-length, press forming and punching, we can provide you with galvanized steel strip, galvanized steel sheet, galvanized corrugated sheet, galvanized perforated sheet and so on.
If the project needs DX51D+Z100 galvanized steel coil, or want to know more about galvanized steel coil application suggestions, you are welcome to inquire further.
