Dx51d AZ150
Dx51D AZ150 Aluminum Zinc Plated Steel is a kind of steel with excellent corrosion resistance, weather resistance, durability and other properties, which is widely used in construction, home appliances, automotive and other fields.
Thickness: 0.3 – 4mm
Width: ≤1500mm (can be customized according to needs)
Length: Cut as required
Type: Coil / Sheet / Strip
Ensure product quality and transportation
Dx51D AZ150 Meaning
- DX51D: It is the steel grade in the European standard EN10346, which belongs to the low carbon cold rolled substrate and is suitable for cold forming process.
- AZ150: “A” means Aluminum (Al), ‘Z’ means Zinc (Zn), “150g/㎡” means the total weight of double-sided Aluminum and Zinc coating is 150g/㎡.
Specification
| Product name | Dx51d AZ150 |
| Thickness | 0.3 – 4mm |
| Width | ≤1500mm (can be customized according to needs) |
| Length | Cut as required |
| AL-ZN Coated | 150g/m² |
| Type | Coil / Sheet / Strip |
| Standard | EN 10346 |
| Processing service | Opening, striping, pressing, etc. |
| Surface treatment | Fingerprint resistance, passivation, oiling, pre-painting, etc. |
| MOQ | 10 tons |
| Packaging | Standard export package or as per your requirements |
Dx51D AZ150 Advantages
Excellent Corrosion Resistance
The surface coating consists of 55% aluminum, 43.4% zinc, etc. The combination of aluminum + zinc makes it more resistant to corrosion; and the 150g/m² plating is thicker to further enhance the corrosion resistance.
Excellent weatherability
High thermal reflectivity, high temperature resistance (stable performance at over 300 degrees Celsius), not easy to fade and oxidize for outdoor use.
Excellent processing performance
Low-carbon base material (DX51D) is easy to press, shear, bend, weld and other operations, the plating adhesion is strong, and it is not easy to crack or peel off during processing.
Excellent decorative properties
Smooth and flat surface, can be pre-painted with colorful paint (PE/PVDF), rich in color and highly decorative.
High economy
High initial cost, but long life and low maintenance cost, more cost-effective in the long run.
Dx51D AZ150 Applications
- Construction field: metal roofs, walls, metal sandwich panels, soundproof walls, gutters, ventilation ducts.
- Home appliance field: shells of refrigerators, washing machines, air conditioners and other home appliances, oven liners, microwave oven shells, range hood panels and so on.
- Automobile field: automobile body, shell, inner plate, bottom plate, muffler, exhaust pipe, wiper attachment, fuel tank, etc.
- Other fields: grain bin, solar energy bracket, cable bridge, storage shelves, chimney pipe, fluorescent lamp cover, warm boiler, etc.
Dx51d AZ150 Aluminum Zinc Plated Steel Weight
- Substrate Weight (kg) = Length (m) × Width (m) × Thickness (mm) × 7.85
- Coating Weight (kg) = Length (m) × Width (m) × 0.15kg/㎡（150g/㎡）
- Total Weight (kg) = Substrate Weight + Coating Weight
- Weight per Square Meter (kg) = Thickness (mm) × 7.85 + 0.15
Why Choose Us?
- We have an aluminum zinc plating production line, which is produced with high quality raw materials, and the plating range is AZ30-AZ150g/㎡, with a wide range of thickness.
- The products undergo strict testing, including plating, specification, surface, performance and other aspects of the test, to ensure that the products meet customer requirements.
- With many years of production and export experience, we have developed the most customer-oriented solutions for our customers and successfully exported to more than 120 countries.
Wanzhi Steel is an ISO 9001, ISO 14001 and other certified company with high quality metal coating products, trusted by customers, if you are interested in Aluminum Zinc Plated Steel products, please contact us for more details.
