PPGL
Aluminum-zinc plated color coated coil is mainly composed of aluminum-zinc plated substrate and coating in terms of structural analysis. Aluminum-zinc plated substrate provides excellent corrosion and heat resistance for PPGL, while the multiple colors of the surface coating provide PPGL with a beautiful appearance.
Place of Origin: Shandong, China
Design Style: Customizable
Thickness: 0.12 – 1.2mm or as required
Width: 600 – 1250mm or as required
Transportation:By sea or Land transportation
Ensure product quality and transportation
PPGL steel coil introduction
PPGL steel coils are usually made from aluminum-zinc plated steel sheet (55% aluminum, 43.4% zinc, 1.6% silicon) as the substrate, which is treated with grease, phosphate, chitin, and finally coated with organic coatings (PE, SMP, HDP, PVDF, etc.) by baking.
![Color Coated Aluminum Zinc Coil Structure](https://wanzhi-steel.com/wp-content/uploads/2024/05/Color-Coated-Aluminum-Zinc-Coil-Structure-1.jpg)
PPGL Steel Coil Specifications
Product Name | PPGL(Pre-Painted Galvalume Steel Coil) |
Substrate | GL |
Thickness | 0.12mm-1.2mm |
Width | 600mm-1250mm |
Coil weight | 3-5tons or as required |
Coatings | PE,SMP,HDP,PVDF |
Coating Thickness | Top: 11-35 um,Back:5-14 um |
Paint Surface | matt/wrinkled/glossy/Emboss |
Colors | As per RAL Color,can be customized |
Monthly Production | 5,000-10,000tons |
Package | Standard Export Package |
Common RAL Colors
PPGL steel production video
Product application
1. Construction field: PPGL is widely used in construction field, such as roofing, wall panels, eaves, garage, ceiling, doors and windows.
2. Home Appliances: PPGL is generally used in home appliance panels, such as refrigerators, washing machines, air conditioners, electronic microwave ovens, electrical cabinets and so on.
3. Agricultural field: PPGL is generally used in greenhouses, chicken coops, stables, haylofts, barns, sheds, etc. in agricultural field.
4. Furniture field: In the furniture field, PPGL is usually used to make steel furniture such as shutters, doors, garage doors, iron frames, and so on.
Packing Details
![packing](https://wanzhi-steel.com/wp-content/uploads/2024/05/packing-1.jpg)
![packing](https://wanzhi-steel.com/wp-content/uploads/2024/05/packing1-1.jpg)
How to choose ppgl steel coil
1. the quality of the substrate: choose PPGL with uniform coating and strong adhesion;
2. coating quality: choose PPGL with full coating, no bubbles, no cracks and uniform color;
3. dimensional accuracy: choose PPGL with small dimensional error and consistent diagonal;
4.surface quality: choose PPGL with flat, smooth and flawless surface.
![ppgl](https://wanzhi-steel.com/wp-content/uploads/2024/05/ppgl4.jpg)
![ppgl](https://wanzhi-steel.com/wp-content/uploads/2024/05/ppgl-1.jpg)
Advantages of PPGL
1. High corrosion resistance: PPGL has excellent corrosion resistance due to its 55% aluminum content.
2. High heat reflectivity: PPGL’s high heat reflectivity keeps buildings cool in the summer.
3. Weather Resistance: Aluminized zinc plated steel can withstand harsh environments.
4. Easy to process: PPGL is easy to process, it can be cut, pressed and molded to create a variety of shapes, such as curved, rectangular, oval and tubular.
5. Beautiful appearance: PPGL is colorful and available in a variety of colors, the colors can also be customized, contact WANZHI for custom colors; the surface is smooth and can meet the decorative requirements.
CONCLUSION
PPGL steel is a key product produced by WANZHI and also has an advantage in the industry, the service life can reach more than 25 years under normal circumstances, compared with PPGI, PPGL has a smoother surface, better corrosion resistance and high temperature resistance, in addition, it can be cut, stamped, and anisotropic to meet the different needs, wanzhi steel is a production of PPGL steel factory, can offer you ex-factory price, welcome to contact us.
Applications | Construction external use / Construction internal usee / Household appliancee / Furnituree / Others |
---|---|
Surface finish | Normal coated / Embossed / Printed / Checker / Suede / Pearly-lustre |
Types of top coatings | PE / Silicon modified polyesters / High-durability polyester / Polyvinylidene fluoride |
Base metal | Regular / Self dleaning / Antistatic / Antisepite / Adiabatic |
