RAL 5005 PPGI PPGL
RAL 5005 PPGI PPGL has beautiful appearance and strong decorative properties. The paint coating combined with the corrosion-resistant substrate (GI/GL) makes it have a longer service life and more economic benefits.
Thickness: 0.12mm – 1.2mm
Width: Standard coil widths: 1000mm, 1250mm; 600mm, 914mm, 1000mm, 1200mm (slits available upon request)
Coating Composition: GI Steel (pure zinc), GL Steel (55% aluminum, 43.4% zinc)
Ensure product quality and transportation
RAL 5005 is a signal blue with a high color saturation. It is often used as a paint coating for PPGI and PPGL. It offers excellent corrosion and weather resistance, making it a cost-effective pre-painted steel.
Specification
| Product Name | RAL 5005 PPGI PPGL Coil & Sheet |
| Thickness | 0.12mm – 1.2mm |
| Width | Standard coil widths: 1000mm, 1250mm; 600mm, 914mm, 1000mm, 1200mm (slits available upon request) |
| Substrate | GI Steel, GL Steel |
| Coating Composition | GI Steel (pure zinc), GL Steel (55% aluminum, 43.4% zinc) |
| Coating Weight | Z30 – Z275g/㎡, AZ30 – AZ150g/㎡ |
| Grade | SPCC, SGCC, CGCC, DX51D, DX52D, DX53D, DX54D, S250GD, S350GD, S550GD, A653, etc. |
| Paint Type | PE,PVDF,HDP,SMP |
| Paint Thickness | 15 – 25 μm |
| Production Standards | EN 10169, ASTM, JIS G 3312, GB/T 12754 |
| Processing Services | Cutting, slitting, punching, profiling, stamping, etc. |
| Coil inner diameter | 508mm (20 inches) or 610mm (24 inches) |
| Coil outer diameter | Depending on weight, typically between 1.2m and 1.8m |
| MOQ | 5 tons |
| Packaging | Standard export package or as per your requirements |
Advantages
- Excellent Corrosion Resistance: Both PPGI and PPGL are corrosion-resistant, with PPGL being more resistant. Combined with a paint coating, it offers enhanced resistance to external corrosion.
- Lightweight, High Strength, and Easy Processing: Both offer excellent processability, making them easy to cut, form, and stamp.
- Decorative and Functional: RAL 5005 offers vibrant colors and strong decorative properties. Antimicrobial properties can be achieved by adding silver ions.
Applications
- Architecture: Roofs and curtain walls of industrial plants and stadiums; decorative components (awnings, billboards, etc.).
- Home Appliances: Casings of appliances such as air conditioners, refrigerators, and microwave ovens. Antimicrobial coatings can be used on medical device casings.
- Transportation and Public Facilities: Side and roof panels of trucks and containers, fuel tank covers, highway noise barriers, signboard backings, etc.
Packaging
Why Choose Us?
We are a professional color-coated steel coil manufacturer in China, with over 14 years of production and export experience. Our products offer a wide range of colors (according to the RAL color chart), stable performance, and high customer reviews. If your project requires RAL 5005 PPGI/PPGL or other color-coated steel products, please feel free to contact us for details.
