Galvanized Pipe Prices
Regularly update the price information of galvanized pipes of different specifications and different zinc layers.
LatestGalvanized Pipe Prices
Updated: 2025-8-29
| Specifications | Outer Diameter (mm) | Wall Thickness (mm) | Length (m) | Weight (kg/m) | Zinc Layer Thickness | Zinc Layer Weight | Galvanizing Process | Price (USD/Ton) |
| DN15 Galvanized Pipe | 21.3 | 2 | 6 | 1.06 | 40μm | 280g/m² | HDG | $950-1,000 |
| DN15 Galvanized Pipe | 21.3 | 2 | 6 | 1.06 | 60μm | 420g/m² | HDG | $980-1,030 |
| DN20 Galvanized Pipe | 26.9 | 2.3 | 6 | 1.63 | 40μm | 280g/m² | HDG | $930-980 |
| DN20 Galvanized Pipe | 26.9 | 2.3 | 6 | 1.63 | 80μm | 560g/m² | HDG | $1,000-1,050 |
| DN25 Galvanized Pipe | 33.7 | 2.6 | 6 | 2.42 | 60μm | 420g/m² | HDG | $920-970 |
| DN25 Galvanized Pipe | 33.7 | 2.6 | 6 | 2.42 | 80μm | 560g/m² | HDG | $950-1,000 |
| DN32 Galvanized Pipe | 42.4 | 2.8 | 6 | 3.13 | 60μm | 420g/m² | HDG | $900-950 |
| DN32 Galvanized Pipe | 42.4 | 2.8 | 6 | 3.13 | 80μm | 560g/m² | HDG | $930-980 |
| DN40 Galvanized Pipe | 48.3 | 3 | 6 | 3.84 | 60μm | 420g/m² | HDG | $880-930 |
| DN40 Galvanized Pipe | 48.3 | 3 | 6 | 3.84 | 80μm | 560g/m² | HDG | $910-960 |
| DN50 Galvanized Pipe | 60.3 | 3.2 | 6 | 5.29 | 60μm | 420g/m² | HDG | $860-910 |
| DN50 Galvanized Pipe | 60.3 | 3.2 | 6 | 5.29 | 80μm | 560g/m² | HDG | $890-940 |
| DN65 Galvanized Pipe | 76.1 | 3.5 | 6 | 7.11 | 60μm | 420g/m² | HDG | $840-890 |
| DN65 Galvanized Pipe | 76.1 | 3.5 | 6 | 7.11 | 80μm | 560g/m² | HDG | $870-920 |
| DN80 Galvanized Pipe | 88.9 | 4 | 6 | 9.81 | 60μm | 420g/m² | HDG | $820-870 |
| DN80 Galvanized Pipe | 88.9 | 4 | 6 | 9.81 | 80μm | 560g/m² | HDG | $850-900 |
| DN100 Galvanized Pipe | 114.3 | 4.5 | 6 | 14.13 | 60μm | 420g/m² | HDG | $800-850 |
| DN100 Galvanized Pipe | 114.3 | 4.5 | 6 | 14.13 | 80μm | 560g/m² | HDG | $830-880 |
| DN125 Galvanized Pipe | 139.7 | 5 | 6 | 19.15 | 60μm | 420g/m² | HDG | $780-830 |
| DN125 Galvanized Pipe | 139.7 | 5 | 6 | 19.15 | 80μm | 560g/m² | HDG | $810-860 |
| DN150 Galvanized Pipe | 165.1 | 5.5 | 6 | 25.75 | 60μm | 420g/m² | HDG | $760-810 |
| DN150 Galvanized Pipe | 165.1 | 5.5 | 6 | 25.75 | 80μm | 560g/m² | HDG | $790-840 |
| DN200 Galvanized Pipe | 219.1 | 6 | 6 | 36.6 | 60μm | 420g/m² | HDG | $740-790 |
| DN200 Galvanized Pipe | 219.1 | 6 | 6 | 36.6 | 80μm | 560g/m² | HDG | $770-820 |
| DN15 Electrogalvanized Pipe | 21.3 | 2 | 6 | 1.06 | 15μm | 105g/m² | EG | $1,100-1,150 |
| DN25 Electrogalvanized Pipe | 33.7 | 2.6 | 6 | 2.42 | 15μm | 105g/m² | EG | $1,050-1,100 |
Get an Accurate Quote
Our dedicated team is always on hand to provide you with the latest pricing and expert technical support.
Product Description
- Galvanizing Process: Hot-dip galvanizing (high corrosion resistance), electrogalvanizing (smooth surface).
- Length: Fixed length 6 meters, custom lengths available.
- Outer Diameter Tolerance: ±0.5mm to ±1.0% (depending on specifications).
Recommended Products
Wanzhi Can Supply Galvanized Pipe
Technical Parameters
15-200mm
Nominal Diameter
2.0-6.0mm
Wall Thickness
7.85 g/cm³
Material Density
GB,ASTM,JIS,EN
Implementation Standards
Galvanizing Production Process
Surface Treatment
Pickling to remove scale, oil, and other impurities
Flux Treatment
Immersion in flux to prevent oxidation
Hot-Dip Galvanizing
Galvanizing in a 450°C zinc bath
Cooling
Water or air cooling for final shaping
Quality Inspection
Thickness measurement and appearance inspection
Product Advantages
Excellent corrosion resistance
The zinc coating provides electrochemical protection, effectively preventing rust.
Long service life
The heavy-duty zinc coating can last over 25 years.
Low maintenance costs
No frequent paint maintenance is required, saving future costs.
Easy installation
Standard specifications, simple connections, and quick installation.
Environmentally friendly and recyclable
100% recyclable, meeting environmental standards.
Applications
Water supply systems
Water pipes, fire protection pipes, water supply and drainage systems.
Industrial piping
Chemical piping, oil and gas pipelines, compressed air piping.
Building structures
Scaffolding, steel structure supports, guardrails and handrails.
Agricultural irrigation
Farm irrigation pipes, greenhouse structures.
Electricity and telecommunications
Cable protection pipes, communication line casings.
Warehousing and logistics
Racking structures, storage equipment frames.
