Steel Flat Bar

Specifications of Steel Flat Bar

Product Name	Steel Flat Bar
Edge width	12 – 300mm
Edge thickness	3 – 60mm
Length	6m, 9m, 12m or Customized
Material	Q195,Q235,Q355,SS400,A36,S235,S355,201,304,316L, etc.
Standard	GB, JIS, BS, EU, ASTM
Samples	Free samples
MOQ	25 tons
Packing	Standard export packing or as required

Steel Flat Bar Application

Construction field

• Structural reinforcement: used as reinforcement material for walls, eaves, roofs, columns, etc.
• Supporting structure: used as support structure for large steel structures, such as high-rise buildings, bridges, large stadiums, etc.
• Roofing and wall systems: In the roofing and wall systems of light steel buildings, flat steel can be used as purlins or wall beams.
• Staircase manufacturing: flat steel bars are often used to make stair treads and stair handrails.

Machinery manufacturing field

• Machinery parts manufacturing: used to manufacture various mechanical parts, such as gaskets and simple clamps.
• Equipment frames and housings: used to manufacture mechanical equipment frames and housings.

Power industry

• Grounding system: flat steel bars have good conductivity and are widely used in grounding devices of power systems.
• Equipment brackets: flat steel bars can be used to make brackets for power equipment.

Other fields

• Railway transportation: In the manufacture of rail transportation vehicles, flat steel can be used to make handrails, seat brackets and other components inside the carriage.
• Railway facilities: used to manufacture some components of railway tracks, such as railway track brackets and other fixed structures.
• Tool making: Flat steel bars are important raw materials for making hardware tools, such as pliers, wrenches, etc.

Steel Flat Bar Features

1. Shape characteristics

• The cross-sectional shape is regular, and the cross-section of the flat steel bar is rectangular.
• Various sizes can meet different engineering and manufacturing needs.

2. Mechanical performance characteristics

• The flat steel bar has high strength and can withstand large tension, pressure and shear force.
• The flat steel bar has good toughness and will not break easily when subjected to impact or dynamic load.

3. Processing performance characteristics

• The flat steel bar is easy to cut and can be cut using a variety of cutting equipment.
• The flat steel bar is easy to bend and weld.

4. Surface quality and anti-corrosion

• The surface quality of the flat steel bar is good.
• In addition to the anti-corrosion of stainless steel, the flat steel bar can also be anti-corrosion by galvanizing.

Calculation of the weight of steel flat bars

Calculation formula：W (kg/m) = 0.00785 × b × d

Where b represents the weight of each meter of flat steel bar (kg/m), b represents the side width of the flat steel bar (mm), and d represents the thickness of the flat steel bar (mm).

Examples of weight calculation of flat steel bars of different specifications:

Width (mm)	Thickness (mm)	Weight per meter (kg/m)
30	7	0.00785×30×7=1.6485
40	5	0.00785×40×5=1.57
50	6	0.00785×50×6=2.355
60	8	0.00785×60×8=3.768
80	10	0.00785×80×10=6.28

Steel Flat Bar Price

The price information of flat steel is mainly affected by the material and specifications. The biggest difference is between stainless steel and carbon steel. The following shows you the price of stainless steel flat steel bars and carbon steel flat steel bars.

Carbon steel flat steel bar price

Taking Q235 material as an example, the price of carbon steel flat bar is about US$500/ton – US$700/ton

Stainless steel flat steel bar price

• The price of hot-rolled stainless steel flat steel bars of 201 material is about US$1070/ton.
• The price of small-sized stainless steel flat steel bars of 304 material is about US$1647/ton – US$2059 /ton, and the price of large-sized stainless steel flat steel bars is about US$2470/ton – US$3432/ton.
• The price of hot-rolled stainless steel flat steel bars of 316 material is about US$2059/ton – US$3567/ton.

The prices of flat steel bars of different materials, widths and thicknesses are different. You can contact us to determine the accurate price information.

Why Choose Us

• Made of advanced technology, the surface is smooth and textured.
• The product specifications are complete and customized.
• The product has good bearing capacity, is not easy to deform, and is stable and strong.
• The size is accurate, and it is precisely cut according to your requirements, and the cut is smooth and flat.
• With 14 years of export experience, sufficient supply, and can quickly complete customer orders.

Wanzhi Steel is one of the leading flat steel bar suppliers in China, with a large inventory of common specifications and a full range of sizes to meet your needs for flat steel bars for any project. If you have any questions about flat steel bars, please feel free to contact us.
