12 Gauge Galvanized Wire

Specifications

Product Name	12 Gauge Galvanized Wire
Thickness	12 gauge (2.8mm)
Weight	0.048 kg/m
Base material	SAE 1008, SAE 1035Q195, Q235, DC01, etc.
Standard	ASTM, ISO, GB, JIS
Galvanizing type	Hot dip galvanizing / Electro galvanizing
Galvanizing amount	60-300 g/m²
Yield strength	400-600 MPa
Tensile strength	550-700 MPa
Surface treatment	Passivation, oiling, PVC/PE coating, bright, etc
Bundle weight	10kg – 1000kg‌ or as required by customers
MOQ	5 tons
Packing	Standard export packing or as required

12 Gauge Galvanized Wire Application

• Building construction: concrete reinforcement, bundling materials (tying reinforcing bars, fixing scaffolding and formwork), making wall and floor reinforcement nets.
• Agriculture: making breeding fence/farmland isolation net, greenhouse bracket fixing/vineyard support, gardening tying.
• Industrial Manufacturing: Heavy duty screen mesh, heavy duty cargo strapping, machinery and equipment protection mesh, cable armoring, spring manufacturing.
• Handicrafts & Decoration: Ironwork (fencing, ornaments), metal weaving, DIY handmade model frames.
• Others: temporary safety fences, freshwater aquaculture netting fixing, etc.

12 Gauge Galvanized Wire Features

1. Good corrosion resistance: the surface has a zinc layer, which can effectively isolate the corrosive medium and extend the service life. The hot-dip galvanized wire has better corrosion resistance.
2. Moderate strength: 12 gauge galvanized wire has moderate thickness, has a certain strength, and can withstand a certain amount of pressure and tension.
3. Good plasticity: low carbon steel has high toughness and is easy to bend, weave or process into shape.
4. Wide application: it can be processed into various types of products by shearing, bending, and welding, and applied to various scenarios.

Common Wire Gauge Standards Comparison Table

The larger the gauge number (Gauge), the thinner the thickness/diameter.

Why? HISTORICAL PROCESS BACKGROUND: Wire gauges were originally used to indicate the number of times a wire was drawn, and for each draw, the diameter decreased and the number (Gauge) increased by one.

Wire Gauge Size	SWG(mm)	BWG(mm)	Metric(mm)
8	4.06	4.19	4
9	3.66	3.76	–
10	3.25	3.4	3.5
11	2.95	3.05	3.00
12	2.64	2.77	2.8
13	2.34	2.41	2.5
14	2.03	2.11	–
15	1.83	1.83	1.8
16	1.63	1.65	1.65
17	1.42	1.47	1.4
18	1.22	1.25	1.2
19	1.02	1.07	1
20	0.91	0.89	0.9
21	0.81	0.813	0.8
22	0.71	0.711	0.7

Related products

Why Choose Us

• Quality raw materials are selected to ensure the strength and durability of each coil of galvanized wire.
• Provide full-size specification options, with sufficient stock of common specifications, strong production capacity and fast delivery.
• Support standard and customized packaging to ensure zero loss of product transportation.
• Factory direct pricing and exclusive discounts for large orders.

Wanzhi Steel is a leading supplier of galvanized wire in China, with years of experience in the industry, we can provide you with the most suitable galvanized wire solutions, whether you need building tie-ups, fence reinforcement or industrial use.
