Galvanized Wire

Galvanized Wire Specifications

Product Name	Galvanized Wire
Wire Diameter	0.2-8.0mm
Material	Q235, Q195, etc
Zinc Coated	40 – 350g/m²
Tensile Strength	300MPa – 1800MPa
Elongation	15% – 30%
Coil Weight	1kg – 1000kg or as your required
MOQ	10 tons
Packing	Coiled wire: Plastic film inside, burlap bag or woven bag outside.
	Axle wire: Plastic wrapping, carton outside

Galvanized Wire Application

Galvanized wire is widely used in many industries such as construction, agriculture, and industry due to its excellent performance.

1. Construction field

• Making protective facilities such as guardrails and safety nets on construction sites.
• Used to bundle building materials such as steel bars and steel pipes. Auxiliary reinforcement materials for building structures.

2. Agriculture field

• Used to make fences for farmland, orchards, and farms.
• Used to build frames, brackets and other structures for greenhouses.

3. Industrial applications

• Made into screens and filters.
• Used to make various packaging materials.
• Used to manufacture various metal parts and metal accessories, such as brackets, hanging parts, connectors, etc.

4. Crafts and household items

• Woven crafts, such as wire flower baskets, wire sculptures, etc.
• Used to make household items such as hangers, curtain rods, and racks.

Galvanized Wire Features

1. Strong corrosion resistance: The zinc layer on the surface can prevent corrosive substances from eroding the inside of the steel wire.
2. Good mechanical properties: Galvanized wire has high strength and good toughness, and can withstand greater forces.
3. Easy to process: Galvanized wire can be bent, welded, woven and other processing methods to make different products.
4. Beautiful: The galvanized wire has uniform color, smooth and bright surface, and has a certain decorative effect.

Galvanized Wire Production Process

1. Raw material preparation

• Use high-quality low-carbon steel wire rod as raw material.
• Peel the low-carbon steel wire rod to remove the oxide layer and impurities on the surface.

2. Drawing and pickling

• Put the treated low-carbon steel into the wire drawing machine and make the metal wire of the required diameter through multiple drawing.
• Pickling the drawn steel wire to remove impurities such as rust and scale on the surface.

3. Water washing and drying

• After pickling, the steel wire should be washed immediately to remove the residual acid.
• After washing, the steel wire is dried to prevent oxidation of the product.

4. High temperature annealing

• In order to eliminate the internal stress generated during the drawing process, the dried steel wire is placed in the annealing furnace for high temperature (700℃-900℃) annealing.
• The dried metal wire is annealed to reduce its hardness and brittleness and improve its plasticity and toughness.
• The annealed steel wire needs to be slowly cooled.

5. Galvanizing treatment

• Before galvanizing, the steel wire is pre-treated by degreasing and cleaning to ensure a clean surface and improve the adhesion of the zinc layer.
• The steel wire is galvanized by hot-dip galvanizing and electro-galvanizing.
• After galvanizing, the excess zinc liquid on the surface of the steel wire is removed by vibration, centrifugation, etc.

6. Cooling and passivation

• The galvanized steel wire is cooled.
• After cooling, it is purified to enhance its anti-oxidation and corrosion resistance.

7. Post-treatment

• The galvanized wire is fully inspected, including appearance inspection, size measurement, zinc layer thickness detection, adhesion test, etc.
• The galvanized wire is packaged, and the packaging methods include spool wire, coil, etc.

Galvanized Wire Weight Calculation Formula

Galvanized wire weight calculation

Weight (kg) = wire diameter (mm) × wire diameter (mm) × length (m) × 0.00617.

For example: the wire diameter (diameter of galvanized wire) is 2.5mm, and the weight of galvanized wire with a length of 10m = 2.5 × 2.5 × 10 × 0.00617 = 0.385625kg

Theoretical weight table

Gauge	UK SWG (mm)	BWG (mm)	Metric (mm)	Theoretical Weight (kg/km)
8 gauge	4.06	4.19	4	98.72
9 gauge	3.66	3.76	–	75.58
10 gauge	3.25	3.4	3.5	55.53
11 gauge	2.95	3.05	3	48.37
12 gauge	2.64	2.77	2.8	38.56
13 gauge	2.34	2.41	2.5	27.47
14 gauge	2.03	2.11	–	19.99
15 gauge	1.83	1.83	1.8	16.8
16 gauge	1.63	1.65	1.65	12.09
17 gauge	1.42	1.47	1.4	8.88
18 gauge	1.22	1.25	1.2	6.17
19 gauge	1.02	1.07	1	5
20 gauge	0.91	0.89	0.9	3.95
21 gauge	0.81	0.813	0.8	3.02
22 gauge	0.71	0.711	0.7	2.22

Galvanized Wire Price

The price of high-zinc galvanized wire is usually around $480 to $950 per ton.

The price of galvanized wire is affected by many factors, such as raw material cost, production process, market supply and demand, specifications, etc.

It is recommended that you specify the diameter, zinc layer thickness, length and other information of the galvanized wire when inquiring.

Why Choose Us

• We are a supplier with 14 years of export experience, ISO 9001:2015 certified, and our products are exported to more than 120 countries.
• The galvanized wire we supply is made of high-quality steel such as Q195 and Q235, which ensures the strength and durability of the galvanized wire.
• Fast delivery, with common specifications in stock, and sufficient production capacity, can be completed in a short time to ensure delivery time.
• Full size, and provide standard seaworthy packaging or packaging according to customer requirements to ensure the integrity of the product.
• Under the premise of ensuring quality, we provide you with the best price, and the price discount for large-volume orders is even greater.

Wanzhi Steel is a professional galvanized wire supplier in China, which can provide you with galvanized wire of various models and different uses. If you have purchasing needs or any questions about galvanized wire, please feel free to contact us.
