2 Inch Galvanized Pipe

Specifications

Product Name	2 Inch Galvanized Pipe
Nominal Diameter	2 inches (Actual OD: 60.3 mm)
Wall Thickness	2 mm – 8 mm
Inner Diameter Range	52.5 mm – 54.4 mm (determined by wall thickness)
Length	6 meters or customized (1-12 meters)
Base Material	Q235B, Q195, Q345B, Gr.A, Gr.B, Gr.C, S235JR, STK400
Standards	ASTM, GB, EN, JIS
Zinc Layer Thickness	≥ 65 μm
Technology	Hot-dip galvanized pipe, electrogalvanized pipe
Tensile Strength	≥ 375 MPa
Packaging	Bundles (20-30 pieces/bundle)
Delivery Time	10-20 business days
MOQ	10 tons
Packing	Standard export packing or as required

2-Inch Gi Pipe Advantages

1. Excellent Corrosion Resistance: Galvanized with a zinc layer thickness of ≥65μm, it offers excellent corrosion resistance and a service life of 25-30 years outdoors.
2. High Strength: Yield Strength ≥235 MPa, Tensile Strength ≥375 MPa, and strong load-bearing and pressure-bearing capabilities.
3. Cost-Effective: Compared to stainless steel pipe, it offers significantly lower costs while maintaining excellent corrosion resistance.
4. Easy Installation: Multiple connection options, including threads, flanges, and clamps, are readily available for cutting and welding, simplifying installation and maintenance.

2 Inch Gi Pipe Applications

• Construction: Scaffolding beams, steel structure auxiliary columns (used with H-beams), temporary building frames, trusses, etc.
• Fire Protection Systems: Sprinkler system main pipes, fire hydrant connection pipes, escape ladder brackets, etc.
• Agriculture: Irrigation main pipes, greenhouse frames, livestock fence supports, etc.
• Industrial: Shelving structures, conveyor supports, pipe bridges, water pipelines (for clean water and common solvents), etc.
• Municipal Facilities: Traffic guardrail posts, streetlight pole lining pipes, main water supply pipes, main drainage pipes, etc.

Theoretical Weight of 2-Inch Galvanized Pipe

The weight of 2-inch galvanized pipe varies depending on the wall thickness.

Theoretical Weight Calculation Formula for Galvanized Pipe (Round Pipe) = (Outer Diameter (mm) – Wall Thickness (mm)) × Wall Thickness (mm) × 0.02466

Theoretical Weight

Outer Diameter (mm)	Wall Thickness (mm)	Theoretical Weight(kg/m)	6m Weight(kg)	pipes/1 ton
60.3	2.5	3.55	21.38	46-47pipes
60.3	2.77	3.92	23.52	42-43pipes
60.3	3.25	4.57	27.43	36-37pipes
60.3	3.91	5.44	32.62	30-31pipes
60.3	4.57	6.18	37.1	26-27pipes
60.3	5.54	7.47	44.8	22-23pipes
60.3	8.74	10.88	65.3	15-16pipes

If you want to calculate the weight of galvanized square pipe, or galvanized round pipe of other thicknesses, you can use our Metal Pipe Calculator.

2 Inch Galvanized Pipe Price

Depending on factors such as the production process, zinc raw material price, base material price, specifications, quantity, and ocean freight, the price per ton of 2-inch galvanized pipe is approximately US$750-850. For accurate galvanized pipe pricing information, please contact us.

FAQ About 2 Inch Gi Pipe

Q1: What does the “2-inch” in 2-inch galvanized pipe refer to? Is it a round pipe?

A: “2-inch” refers to the nominal diameter (DN50), not the actual outer diameter; it defaults to round galvanized steel pipe.

Q2: What is the service life of a 2-inch galvanized pipe?

A: Hot-dip galvanized pipe has a long service life. In normal atmospheric conditions, it has a service life of approximately 25-30 years; in humid/coastal environments, it has a service life of approximately 10-15 years.

Q: Can 2-inch galvanized pipe be welded?

A: It can be welded, but it depends on whether the zinc coating is affected by welding. If so, re-coating with galvanizing paint or cold-spraying is necessary.

Why Choose Us

• We utilize high-quality raw materials and advanced production technology to ensure a zinc coating thickness that meets standards and provides stable product performance.
• Galvanized pipes offer a wide range of outer diameters, from 21.3 to 273mm, in various specifications to meet your project needs.
• Our products undergo rigorous testing, including appearance, zinc coating, and mechanical properties, to ensure they meet customer requirements and standards.
• In addition to galvanized pipes (square, round, and rectangular), we also supply galvanized angle steel, galvanized channel steel, and more.

Wanzhi Steel is a professional galvanized steel pipe supplier in China with over 14 years of export experience. We are ISO 9001, ISO 14001, and ISO 45001 certified. We offer a comprehensive range of galvanized pipe specifications and offer free samples. Please feel free to contact us for purchasing needs.
